U8143-OSL OSL band Light Source Super radiation fluorescence light source
The light source adopts high precision automatic power control (APC) and automatic temperature control (ATC) technology, has high short-term stability and long-term stability, continuous light working mode.
Super Intensity light emitting Diode (SLED) is a new type of light emitting diode with special technology to greatly improve the output power, and its biggest advantage is large output power. According to the working wavelength, it can be divided into 1300nm SLED, 1480nm SLED, 1550nm SLED, 1620nm SLED and so on.
Specification
| Model # | U8143-OSL |
Operation Wavelength | 1260 ~1360, 1460~1530, 1565~1625 nm |
| Single Band wide @-10 dB | ≥60 nm |
| Output Power | ≥9dBm |
| Spectral Density | ≥-26dBm/nm |
| Connector Type | FC/APC (other adaptor can be customized) |
Spectral Density Stability within 15mins | ＜± 0.03 dBm/nm |
Output Power Stability within 15mins | ＜±0.01 dB |
Output Power Stability within 8 hrs | ≤± 0.05 dB |
| Operation Model | CW |
| Fiber Type | Single Mode SFM-28 |
| Operation Temperature | 0 ～ +40℃ |
| Storage Temperature | -30 ～ +80℃ |
| Power Supply | AC 110 ~ 220 V±10%, 50Hz/60Hz, 20W |
| Dimensions | 235mm W, 55 mm H, 320 D mm |
| Weight | 3.0 kg |
Remark:Single Band Type:U8141,SUh as: U8141-C / L,Double Band Type:U8142,SUh as: U8142-CL
Three Band Type:U8143 SUh as: U8143-OSL, Full Band Type: U8144.
All spectrum and power stability tests were carried out in continuous optical output operation mode at ambient temperature of 25℃ (+/-2℃ deviation) and after the module was energized and preheated for 30 minutes.
|
|
