C Band ASE Light Source with Operation Wavelength1527 ~ 1565nm
UC8142C C Band ASE Light Source with Operation Wavelength1527 ~ 1565nm
Specification
| Model # | UC8142CL-A |
| Operation Wavelength | 1525 ~ 1610nm |
| @-10dB Spectral bandwidth@-10dB | ≥ 85nm |
| Output Power (Option) | 20 mW |
| Spectral Density | ≥ -15dBm/nm |
| Connector Type | FC/APC (other adaptor can be customized) |
Spectral Density Stability within 15mins | ＜± 0.02 dBm/nm |
Output Power Stability within 15mins | ＜±0.01 dB |
Output Power Stability within 8 hrs | ≤± 0.05 dB |
| Operation Model | CW |
| Fiber Type | Single Mode SFM-28 |
| Operation Temperature | 0 ～ +40℃ |
| Storage Temperature | -30 ～ +80℃ |
| Power Supply | AC 110 ~ 220 V±10%, 50Hz/60Hz, 20W |
| Dimensions | 235mm W, 55 mm H, 320 D mm |
| Weight | 2.0 kg |
UC8142CL-A CL-band ASE broadband light source adopts erbium-doped fiber gain amplification, combined with spectral flattening technology, and butterfly packaging devices. The single-band continuous output light source is constructed by high stability driving and controlling circuit. The band bandwidth can reach 85nm.
UC8142CL-A CL Band ASE light source has the advantages of high power stability, small size, fast start and affordable price. It provides the output of the broadband light source in the wavelength range of 1525 ~ 1610 nm.
|
|
