48Ch Multimode Light Source With Wavelength Range 1529.55~1567.13nm

Product specification

UC8130C-itu48 is a 48-channel ITU wavelength comb light source customized by UC Instrument. The light source system consists of 48 C-band ITU lasers, their drive and control circuits, a 1x48 channel Mux combiner, an optical attenuator and an optical power meter.

The light source system has the following characteristics:
1.48 channel ITU wavelength combined to one output, forming a comb light source;
2. The output power of the light source is adjustable, and the 48-channel single power can be fine-tuned;
3. The output of light source has power monitoring function;
4. The comb light source achieves equal power output at each wavelength;
5. 48 Channel light source is controlled by computer, which can be turned on and off at will;
6. 48 channel power can be adjusted separately, and the adjustment accuracy can reach ±0.01dB;




The power supply requirements
The UC8130C-ITU48 complies with overvoltage Level II regulations. The operating voltage is 100 ~ 240V AC voltage, the frequency range is 48 ~ 66Hz, the operating voltage is 115V, the maximum consumption current is 230mA; When the operating voltage is 230V, the maximum consumption current is 120mA.
USB port
The USB interface is a standard 4-core B-type interface, which can be connected to UC8130C-ITU48 and PC, and the instrument can be controlled by monitoring software.
USB connection cable
The length of the USB cable cannot exceed 5 m. Otherwise, only a third-party USB peripheral extender can be used. Generally, the maximum extension length can reach 50 m.
RS232 serial port
The serial port parameters of the instrument are set to a fixed value. The serial port parameter Settings of the computer must match the instrument parameter Settings.
RS232 interface pin definition
